Riveter, long arm, with Collecting Bottle
IMPORTANT
Read the operating instructions and all safety instructions contained therein carefully before using the
product. Use the product correctly, with care and only according to the intended purpose. Non-
compliance of the safety instructions may lead to damage, personal injury and to termination of the
warranty. Keep these instructions in a safe and dry location for future reference. Enclose the
operating instructions when handing over the product to third parties.
INTENDED USE
This tool is a "short" long arm riveter which can operate up to 3/16" (4.8 mm) stainless steel rivets
The tool have shorter handle with double compound hinges that maximize leverage and taking the
hard work out of setting large diameter blind rivets. It is ideal for working in hard-to-reach area. The
jaws made of Cr-Mo steel provides long lasting tool life.
SAFETY PRECAUTION
Caution: Please read this information to help prevent personal injury.
Always wear appropriate safety equipment and clothing when using this product. Study,
understand and follow all instructions provided with this product.
Always wear ANSI approved goggles when using this product.
Always select the correct accessories of the correct size and design for the job that you are
attempting to perform.
Always work in a clean, safe, well-lit, organized and adequately equipped area.
Do not begin repairs without assurance that vehicle is in secure position, and will not move during
repair.
UNPACKING
When unpacking, check if all parts are included. If any parts are missing or damaged, please call your
distributor.
DELIVERY
The heavy duty riveter has 4 different size nose pieces to fit the following size rivets:
2.4mm (3/32"), 3.2mm (1/8"), 4.0mm (5/32") and 4.8mm (3/16")
They are located 2 on each side of the handles. This set should also include a nose piece wrench. All
components can be seen on fig.1.
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
BGS 409
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
