INSTRUCTIONS FOR INSTALLATION

REMINDERS FOR THE INSTALLER

The manufacturer will not be liable for any damage or in-
jury resulting from failure to observe the following rules
• Read this manual carefully. It provides important information
for safe installation, use and maintenance of the appliance.
• Installation, conversion to a different type of gas and applian-
ce maintenance must be carried out by qualifi ed technicians
authorized by the manufacturer, in compliance with current
safety standards and the instructions in this manual.
• Identify the specifi c appliance model. The model number is
detailed on the packing and on the appliance data plate.
• The appliance must be installed in a well-ventilated room.
• Do not obstruct any air vents or drains present on the ap-
pliance.
• Do not tamper with appliance components.
Appliances in the DROP-IN series
• The appliance must be installed in strictc ompliance with the
directions given in the attached drawings.
• Appliances should only be installed on units made of metal
(and not wood and/or other fl ammable materials).
• Take particular care with the power lead: the channelways
must be perfectly smooth with no sharp corners and/or ed-
ges. The lead must not, at any point, be subjected to tempe-
ratures of more than 50°C above normal room temperature.

5 REFERENCE STANDARDS AND LAWS

Install the appliance in compliance with current safety stan-
dards.
Install the appliance in compliance with the prescriptions of
EN1717 and the water pollution regulations in force in your
country.

6 UNPACKING

Check the state of the packing and in the event of damage, ask
the delivery person to inspect the goods.
• Remove the packing
• Remove the protective fi lm from the external panels. Use a
suitable solvent to remove any residual adhesive from the
panels

7 POSITIONING

• The overall dimensions of the appliance and the position of
connections are given on the installation diagram at the start
of this manual.
• The appliance can be installed singly or in combination with
other appliances in the same product range.
• The appliance is not suitable for integrated installation.
• Position the appliance at least 10 cm from adjacent walls.
This distance can be reduced in the presence of non-combu-
stible walls or heat-insulated walls.
7.1 APPLIANCE ASSEMBLY WITH BASE
Follow the instructions provided with the type of support utili-
zed.
7.2 JOINING APPLIANCES TOGETHER IN LINE
• Place the appliances side by side and adjust the tops to the
same height.
All manuals and user guides at all-guides.com
• Unite the appliances using the special unionjoint-coverings

8 FUMES EXHAUST SYSTEM

Create a fumes exhaust system based on the "Type" of ap-
pliance. The "Type" is stated on the appliance data plate.
8.1 APPLIANCE TYPE "A1"
• Position the "A1" type appliance below an extractor hood to
8.2 APPLIANCE TYPE "B21"
• Position the "B21" type appliance below an extractor hood
8.3 APPLIANCE TYPE "B11"
• Fit the "B11" type appliance with a suitable fl ue, available
• Connect the fl ue to a 150/155 mm diameter hose, heat resi-
• Vent to the outside or into an effi cient fl ue. The hose length

9 CONNECTIONS

The position and dimensions of connections are given in the
installation diagram at the start of this manual.
9.1 CONNECTION TO THE GAS SUPPLY
Check the compatibility of the gas supply. Check the details
given on the decals on the packing and on the appliance. Con-
vert the appliance to the local gas type, if necessary. Follow the
instructions in the next paragraph "Conversion to a different
type of gas".
On top appliances a rear connection is also available. Remove
the plug present and screw it tightly onto the front connector.
• A rapid-action gas shut-off valve must be fi tted upstream of
• Do not use connection pipes having a diameter smaller than
• Once the appliance has been installed, check for gas leaks at
9.2 ELECTRICAL CONNECTIONS
Check that the appliance is designed to operate at the voltage
and frequency of the power supply present on site. Check the
details given on the appliance data plate.
• At an easily accessible point upline of the appliance, fi t an
• A fl exible rubber cable with insulation specifi cations not lower
• Connect the power supply cable to the terminal board as
• Secure the power supply cable with the cable clamp.
• Protect the power supply cable on the outside of the applian-
9.3 PROTECTIVE EARTH AND EARTH BONDING CON-
NECTIONS
Connect the appliance to an effi cient ground circuit. Connect
the earth conductor to the terminal with the symbol
next to the main terminal board.
supplied upon request
ensure smoke and fumes generated by cooking are removed
from the appliance manufacturer Follow the assembly in-
structions provided with the fl ue.
stant to 300°C.
must not exceed 3 metres.
the appliance in an easily accessible position.
that of the appliance's gas connector.
the connection points.
all-pole disconnect switch of suitable capacity with a contact
breaking distance of at least 3 mm, and a highly sensitive dif-
ferential protection device. The maximum permitted leakage
current is 1 mA/kW.
than type H05 RN-F must be used for connection.
shown in the wiring diagram supplied with the appliance.
ce with a rigid plastic or metal pipe.
located
