Technical description of the burner

4.1

Technical data

MODEL
OUTPUT 2nd stage
(1)
DELIVERY
(1)
1st stage
FUEL
- Net calorific value
- Density
- Viscosity at 20 °C
OPERATION
NOZZLES
STANDARD APPLICATIONS
AMBIENT TEMPERATURE
COMBUSTION AIR TEMPERATURE
POWER SUPPLY
ELECTRICAL MOTOR
Operating current
Acceleration current
IGNITION TRASFORMER
PUMP J7C delivery (at 12 bar)
pressure range
fuel temperature
ELECTRICAL POWER CONSUMPTION
ELECTRICAL PROTECTION
NOISE LEVELS Sound pressure
(2)
Sound power
Reference conditions: Ambient temperature 20 °C - Barometric pressure 1000 mbar - Altitude 100 m a.s.l.
(1)
Sound pressure measured in manufacturer's combustion laboratory, with burner operating on test boiler and at maximum rated
(2)
output. The sound power is evaluated, in line with the regulations, on a spherical surface centred on the burner and with a radius
of 1 metre.
4.1.1

Accessories (optional):

• RADIO DISTURBANCEPROTECTION KIT
If the burner is installed in places particularly subject to
radio disturbance (emission of signals exceeding 10 V/m)
owing to the presence of an INVERTER, or in applications
where the length of the thermostat connections exceeds 20
metres, a protection kit is available as an interface between
the control box and the burner.
BURNER
Code
20054351
Technical description of the burner
kW
Mcal/h
kg/h
kW
Mcal/h
kg/h
kWh/kg
Mcal/kg
3
kg/dm
2
mm /s max
number
°C
°C max
V
Hz
rpm
W
V
A
A
V1 - V2
I1 - I2
kg/h
bar
°C max
W max
dB(A)
RL 190
3010386
10,2 (10.200 kcal/kg)
Intermittent (min. 1 stop in 24 hours).
Two-stage (high and low flame) and single-stage (all - nothing).
Boilers: water, steam, diathermic oil
400 with neutral ~ +/- 10%
4.1.2

Variants

Model
RL 190
6 GB
RL 190
1423 - 2443
1224 - 2100
120 - 206
759 - 1423
653 - 1224
64 - 120
LIGHT OIL
11,8
0,82 - 0,85
6 (1,5 °E - 6 cSt)
2
0 - 40
60
50 - three-phase
2800
4500
400
9,1
72,8
230 V - 2 x 5 kV
1,9 A - 35 mA
230
10 - 21
90
5870
IP 44
83.9
94.9
Power supply
Code
electrical
20052627 400 V
