OPEraTiON
Settings and displays
4.9

Settings in the parameter menu

4.9.1 Activating the parameter menu
f Briefly press and hold "i" for more than 5 seconds until "P 1" f
appears, then continue by briefly pressing "i".
f In the selected parameter menu, turn the temperature selec- f
tor to the required display / setting.
4.9.2 Parameter menu
menu Description
P 1 ECO water and energy
saving function
P 2 Temperature limit Tmax OFF | 20.0 | 20.5 ... °C or
P 3 Wellness showers
P 4 Automatic water volume
control – set the volume
in the selected unit
P 5 Temperature unit
P 6 Volume unit
P 7 Time format
P 8 Time setting
www.stiebel-eltron.com
Selectable display | Explanations
setting
OFF | ECO1 | ECO2 | ECO3 The ECO function enables you to limit the flow rate to a maximum
value.
Flow rate limit:
6 l/min with "ECO1" | 5 l/min with "ECO2" | 4 l/min with "ECO3" |
No flow rate limit with "OFF".
The temperature limit allows you as a user to restrict the adjustable
68 | 69 ... °F set temperature at the appliance to a maximum value. Check that the
upper temperature limit has been correctly applied.
Your qualified contractor can set an additional temperature limit for
anti-scalding protection. This temperature then dictates the upper
limit of the setting range for the temperature limit function.
OFF | Pro1 | Pro2 | Pro3 | The Wellness shower program lets you choose from 4 different alter-
Pro4 nating shower programs.
WW = domestic hot water, KW = cold water, min = minutes,
sec = seconds
- 1 Cold prevention
To strengthen the body, we recommend finishing off with a cold
shower; this will trigger a reflex in the body to warm up.
WW
- 2 Winter refreshment
An invigorating end to a winter shower with a final warm-up.
WW
- 3 Summer fitness program
A quick contrast shower to increase fitness with a final warm-up.
WW
- 4 Circulation boost program
Shower your arms and legs with cold water to boost circulation. Spray
from the hands and feet towards the body. You can then repeat this
process with hot water.
WW
OFF | 5 | 10 | ... 200 l or With the automatic water volume control, you can preselect a volume
2 ... 52 gal of water, e.g. for filling a bathtub. When the preselected water volume
is reached, the automatic control reduces the flow rate. The automatic
water volume control must be enabled on each occasion prior to fill-
ing the bath.
Example, filling a bath with 80 litres (21 gallons): When the bath has
been filled with 80 litres (21 gallons), the control automatically reduc-
es the flow rate to 4 l/min (1 gpm).
C | F Select the temperature unit for all settings.
L | GAL Select the volume unit for all settings.
24h | 12h Select time format.
--:-- You can set the time using the 12 or 24 hour clock:
- 12 hours from 00:00 - 11:59 = AM | 11:59 - 00:00 = PM
- 24 hours from 00:00 to 23:59
After a power cut, the time needs to be set again.
3 min
KW
3 min
10 sec
10 sec
KW
WW - 10 °C | 50 °F
3 min 10 sec
10 sec
KW
3 min 30 sec
20 sec
KW
Symbol |
display
|
10 sec
10 sec
10 sec
10 sec
30 sec
20 sec
°C | °F
l | gal
AM | PM (only
for 12h)
DCE-X Premium |
| |
