Backrest; Adjusting The Backrest Cover - Küschall COMPACTattract Manual Del Usuario

Pull brake
1. To apply the brake, pull the brake lever backwards as far as
possible.
2. To release the brake, push the brake lever forwards.
The lever of the push handle can be folded back to
facilitate transfers. To do so, pull up the lever and fold
it backwards.

3.3 Backrest

Backrest cover
You can adjust the tension of the backrest cover as required.
1589081-A
All manuals and user guides at all-guides.com

Adjusting the backrest cover

1.
2. Loosen the Velcro® tapes B on the rear of the backrest cover
3. Tighten or loosen the tapes as required then reattach them.
Remove the backrest cushion A.
by simply pulling on them.
WARNING!
Risk of tipping
If the bands are set very loose, the tipping point of
your wheelchair is changed for the worse.
– Ensure that the bands are set correctly.
IMPORTANT!
– Do not overtighten the bands; this is to ensure
that the geometry of the wheelchair is not
changed.
IMPORTANT!
– Only ever tighten the bands when the wheelchair
is unfolded.
Components and their functions
11
