Accessories (not incl. in the scope of delivery)
Mounting sets for DTSH
No. Door thickness
1 37 – 47 mm
2 47 – 57 mm
3 57 – 67 mm
4 67 – 77 mm
5 77 – 87 mm
6 87 – 97 mm
7 97 – 107 mm
Dialock Door Terminals DTSH, DTSH FH - Status: 07.2008 - 732.29.134
Consisting of
1 inner square spindle L=100mm
4 countersunk head screws
DIN 965 M4x30
für DTSH FH
1 inner square spindle L=110mm
4 countersunk head screws
DIN 965 M4x40
for DTSH FH
1 inner square spindle L=120mm
4 countersunk head screws
DIN 965 M4x50
for DTSH FH
1 inner square spindle L=130mm
4 countersunk head screws
DIN 965 M4x60
for DTSH FH
1 inner square spindle L=130mm
4 countersunk head screws
DIN 965 M4x70
for DTSH FH
1 inner square spindle L=160mm
4 countersunk head screws
DIN 965 M4x80
for DTSH FH
1 inner square spindle L=160mm
4 countersunk head screws
DIN 965 M4x90
for DTSH FH
Installation Instructions
Cat. No.
917.90.242
917.90.121
917.90.244
917.90.122
917.90.246
917.90.124
917.90.248
917.90.126
917.90.250
917.90.128
917.90.251
917.90.130
on request
on request
