ADJUSTING THE STEERING ANGLE

BASIC SETTING OF THE CHASSIS ACCORDING TO THE RIDER
WEIGHT
Standard weight of the-
rider (with equipment)

SETTING THE FORK COMPRESSION

WP
KAYABA
1
The steering angle can be changed using the set
screws located on the bottom of the steering
column.
Loosen the nut
until you have the steering angle desired.
1
Tighten the nut and do the same operation on
the other side.
2
Steering angle
lock nut
If the weight of the rider is above or below the
75 à 85kg
standard, compensate by changing the stiffness
of the springs (forks and shock).
Screws
when it is compressed. Turning in the screw-
1
clockwise increases the hydraulic force (and
vice versa).
Remove the caps
the fork.
2
Turn screw
back the number of clicks required.
Setting compression
WP suspension
XPLOR Ø48mm
(racing)
Setting compression
KAYABA (factory)
Replace the cap
and tighten the screw
1
M8
determine the behavior of the fork
2
located at the lower end
1
clockwise to the stop and go
2
Comfort
Standard
Sport
Comfort
Standard
Sport
.
1
2
20Nm
18 clicks
15 clicks
12 clicks
20 clicks
12 clicks
8 clicks
93
