INSTRUMENT PANEL
2. SRP 3040 Analog
Separator differential pressure gauge (psi or kPa)
1.
Network pressure gauge
2.
Operating instructions
3.
4. Thermometer discharge temperature (°C)
Hourmeter compressor's total working hours
5.
ON button (green) OFF button (red)
6.
Emergency shut off button
7.

CONTROL SYSTEM

SRP 3040E - ELECTRONIC INTERFACE VERSION
2
3
SRP 3040E compressors' electronic interface is programmed to perform commands according to the
nominal pressure indicated in the tag identifying the product.
3
FIGURE 12 - INSTRUMENT PANEL - SRP 3040
5
1
A
4
FIGURE 13 - CONTROL SYSTEM - SRP 3040E
7 4
5 6
Indicator light - to indicate if the
8.
compressor is energized
Indicator light - to indicate if the
9.
compressor is in operation
Indicator light - to indicate if the
10.
compressor is unloaded
Indicator light - to indicate overload
11.
of the electric motor
8
9
11 10 2
1
A - UNLOAD SYSTEM INPUT ORIFICE
