Magnetic focus "ALL" when the color temperature is 9300K
fH 15.7kHz 24.8kHz 31.5kHz 48.3kHz 64.0kHz 77.1kHz 93.7kHz 106.3kHz
Defocused value (R) 0
Defocused value (G) 0
Defocused value (B) +30 +30
Magnetic focus "ALL" when the color temperature is 6500K or
5400K
fH 15.7kHz 24.8kHz 31.5kHz 48.3kHz 64.0kHz 77.1kHz 93.7kHz 106.3kHz
Defocused value (R) –15 –15
Defocused value (G) 0
Defocused value (B) +30 +30
Magnetic focus "ALL" when the color temperature is 3200K
fH 15.7kHz 24.8kHz 31.5kHz 48.3kHz 64.0kHz 77.1kHz 93.7kHz 106.3kHz
Defocused value (R) +15 +15
Defocused value (G) 0
Defocused value (B) 0
4PA
fH 15.7kHz 24.8kHz 31.5kHz 48.3kHz 64.0kHz 77.1kHz 93.7kHz 106.3kHz
Defocused value (R) 0
Defocused value (G) 0
Defocused value (B) -30
Example
• Color temperature: 9300K, fH: 31.5 kHz
• Blue magnetic focus "ALL" adjustment level: 130
• Blue "4PA" adjustment level: 130
When you give priority to uniformity:
After correcting "4PA" completely, adjust "4PA" to the value arrived at by
adding the value (–30) in the table from the "4PA" adjustment data.
4PA: 130 + (–30) = 100
When you give priority to spot focus:
After adjusting the magnetic focus "ALL" completely, adjust "ALL" to the
value arrived at by subtracting the value (+15) in the table from the "ALL"
adjustment data.
Magnetic focus ALL: 130 – (+15) = 115
0 0 0 0
0 0 0 0
+15 +5 0
–10 0 0
0 0 0 0
+15 +5 0
+10 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
-30 -30 -30 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
