2.5

Technical data

SECURY 2170 / 2171 / 2178 / 2116 S / 2119 S
„ „ Operating voltage (*):
„ „ Current consumption (*):
„ „ Duty ratio (*):
„ „ Contact load:
„ „
Environment protection grade:
The lever handle(s) of the electrically couplable multi-point locks
is/are coupled in through the operating voltage (or decoupled in the quies-
cent current version).
2.6

Components and accessories

Scope of delivery
„ „ Multi-point lock SECURY 21 EK or 21 S
„ „ Set with connecting cable B 5490 0300, type LiYY 14 x 0.14 mm²,
Length 10 m (SECURY 2116 S / 2119 S: B 5490 0001,
type LiYY 6 x 0.14 mm², Length 8 m).
„ „ Installation and maintenance instructions M-00090-00-0
„ „ Installation instructions 0-46015-L0-0
Optional accessories
„ „ Cable duct
„ „ Cableless electricity transmission SECUREconnect
„ „ A-opener kit
„ „ Additional lock with query
„ „
Additional latchbolt FH
12-24 V DC, stabilised
max. 250 mA
100 %
30 V DC / 2 A or 125 V AC / 1 A
3
(*) not with SECURY 21 S
