Mount the Charger
1
Slide in the stud onto the bracket as per step (1).
Remove the Charger
1
Rotate the cradle horizontally (90 °) as per step (2) & (3).
2
Slide out the cradle as per step (4).
28
English
2
Rotate 90°
Figure 5.4: Placing and Removing the Vehicular Charger from the Mounting Bracket
3
Slide out
Insertion
Removal
