BEZZERA ARCADIA BREWING PROFILE
MOD.

4.4 Equipotential bonding

(Fig. 05)
This bonding, required by some regulations,
avoids electric potential differences between
earthed devices installed in the same room. This
appliance has a terminal located under the base
to connect an external conductor, with a ring ter-
minal to insert between two nuts with a nominal
section in compliance with current legislation.

5 - USE OF MACHINE

5.1 Starting the machine and filling
the boiler with water
Open the water shut-off valve.
Bring the lever of the omnipolar power switch to
the "ON" position.
When the switch (Fig. 01; pos. 9) is pressed in the
"ON" position (light
The display will turn on and show the following
screen:
and by pressing"
the main screen:
Automatic filling of the boiler starts; after filling for
120 seconds, the machine enters an alarm state,
the LED lights on the key pad flash and the water
on)
" you will be taken to
supply to the boiler is cut off. Turn the switch to the
"OFF" position (light
Repeat the operation by operating the same
switch repeatedly times until the pump has com-
pletely filled the boiler and no longer operates.
In the main screen, by pressing the clock icon on
the display:
you access the DATE/TIME menu (para-
graph 5.11.7).
By pressing the following icons:
the touch screen will be in accessible for
cleaning operations
you access the SLEEP menu (control unit
powered and machine off).
you access the PROFILE menu (paragraph 5.8).
you access the USER menu (paragraph
5.11).
you access the AUTO ON/OFF menu (para-
graph 5.11.14).
you access the STEAM menu (paragraph 5.4.1).
you access the GROUP menu (paragraph
5.7).
you access the TEA menu (paragraph 5.5).

5.2 Heating

To make sure that the machine has reached the
right thermal balance between temperature and
pressure, when the display
indicates a pressure between 1 and 1.2 bar (0.1
– 0.12 MPa) corresponding to a temperature
range of 118 to 125°C (245 ad 257°F), open the
steam tap (Fig. 01; pos. 1) and release the steam
into the drip basin 2 or 3 times.
44
