PRODUCT DESCRIPTION:

Figure 1 illustrates the 3M™ DBI-SALA™ Concrete Wedge Anchor. The Concrete Wedge Anchor is a reusable anchor point for
horizontal, vertical, or overhead concrete applications.
Figure 2 illustrates components of the Concrete Wedge Anchor. See Table 1 for Component Specifications. The anchor's End
Termination expands Wedges (F) to secure the anchor in a 20 mm (or .75 inch) mounting hole. A spring-tensioned Trigger (C)
and Retractor Cables (J) release the Wedges to allow removal and relocation to another hole. The Fall Arrest subsystem connects
to Swivel Connector Ring (A) for Fall Arrest, Work Positioning, or Restraint.
System Specifications:
Capacity: 1 Person with a combined weight (clothing, tools, etc.) of no more than 140 kg (310 lbs)
Anchorage: Fall Arrest: The structure to which the anchorage connector is mounted must be capable of sustaining
force in the anticipated directions of loading. Each anchorage point location must be capable of the
following values:
EN 795
The concrete the anchor is secured in must have a compressive strength of 20.7 MPa (3,000 psi). The
Concrete Wedge Anchor is not intended for use in lightweight concrete, hollow block, grout, stone,
wood, steel, or any other substrate. The concrete base material must be at least 12.7 cm (5 in.) thick.
Dimensions: See Figure 1 for the dimensions of each Concrete Wedge Anchor model.
Product Weight: .32 kg ( .71 lbs)
Standards: Tested in accordance with EN 795:2012
Anchorage 22 kN (5000 lbs) minimum breaking strength
Connector
Breaking
Strength
Minimum -40° C ( -40° F)
Service
Temperature
Concrete Minimum Distance
Minimum from Edge/
Thickness: Corner:
Z
≥ 30.5 cm ≥ 15.3 cm (6.0 in)
(12 in)
≥ 25.4 cm ≥ 20.3 cm (7.9 in)
(10 in)
≥ 20.3 cm ≥ 25.4 cm (10 in)
(8.0 in)
≥ 12.7 cm ≥ 30.5 cm (12 in)
(5 in)
NOTE: Drill bits for drilling mounting holes must conform to CE requirements.
Table 1 – Specifications
12 kN (2698 lbs)
Concrete Requirements - See Figure 7
Hole Spacing:
Y
X
≥ 25.4 cm (10 in)
≥ 25.4 cm (10 in)
≥ 25.4 cm (10 in)
≥ 25.4 cm (10 in)
Drilled Hole Minimum Hole
Diameter:
D
20 mm or (3/4 in) ≥ 7.7 cm (3.0 in)
20 mm or (3/4 in) ≥ 7.7 cm (3.0 in)
20 mm or (3/4 in) ≥ 7.7 cm (3.0 in)
20 mm or (3/4 in) ≥ 7.7 cm (3.0 in)
6
.
1
Concrete
Depth: Minimum
Compressive
E
Strength:
F
≥ 20.7 MPa
(3000 psi)
≥ 20.7 MPa
(3000 psi)
≥ 20.7 MPa
(3000 psi)
≥ 20.7 MPa
(3000 psi)
