Figure 6
1. Folded position
4. Insert the carriage bolt (with the bolt head toward
the inside) through the upper or lower square hole in
handle bracket and the upper hole in the handle end
(Figure 7).
Figure 7
1. Handle knob
5. Loosely install the handle knobs onto the carriage bolts.
6. Refer to steps 3 through 5 of
Height (page 9).
2. Operating position
2. Carriage bolt
Adjusting the Handle
3
Installing the Recoil-Starter
Rope in the Rope Guide
No Parts Required
Procedure
Important: To start the engine safely and easily
whenever you use the machine, install the recoil-starter
rope in the rope guide.
Pull the recoil-starter rope through the rope guide on the
handle (Figure 8).
1. Recoil-starter rope
5
Figure 8
2. Rope guide
