BTL7-A/E501-M_ _ _ _-J-DEXC-TA12
Magnetostrictive Linear Position Sensor – Rod Style
13

Type code

Interface:
A = Analog interface, voltage output 0...10 V (factory setting)
E = Analog interface, current output 4...20 mA (factory setting)
Supply voltage:
5 = 10...30 V DC
Output gradient:
01 = 2 outputs, configurable
Nominal length (4-digit):
M0500 = Metric specification in mm, nominal length 500 mm (M0025...M7620)
Rod version, fastening:
J = 6 screws (hole circle 76.2 mm)
Plug:
C = Float plug
Electrical connection:
TA12 = Terminal with 1/2"-14 NPT (conduit entry)
Order example for special version (optional, no influence on Ex characteristics):
BTL7-A501-M0500-J-DEXC-SA_ _ _-TA12
30 english
Type of protection "db" and "t"
BTL7 - A 5 01 - M0500 - J - DEXC - TA12
Flameproof enclosure
