1 Information on this manual

2 Safety instructions

1.3

Symbols used

The following symbols are used in this operating manual
to denote levels of danger, information, activities and
energy-saving tips.
d Danger!
Immediate risk of serious injury or
death!
H
Danger!
Danger of burning and scalding!
a
Caution!
Potentially dangerous situation for the
product and environment!
h
Note
Useful information and instructions.
This symbol points you to energy saving tips. You can
put this setting into effect by means of the heat pump
control system, among other things.
• Symbol for a necessary task
1.4

Applicability of the manual

This manual applies exclusively to heat pumps with the
type designations listed in Table 0.1.
2 Safety instructions
Observe the following safety instructions and regula-
tions when operating the heat pump:
• Take advantage of the extensive instruction in the
operation of the heat pump provided by your
specialist technician.
• Carefully read through this operating manual.
• Only carry out activities that are described in this
operating manual.
H Danger!
Risk of burning as a result of contact
with heat pump components!
High temperatures can appear on heat
pump components.
Do not touch any uninsulated pipes on
the heat pump.
Do not remove any of the cladding
sections (apart from the pillar cover,
see Chap. 1.2).
4
All manuals and user guides at all-guides.com
2.1
The heat pump is delivered with an operational filling of
R 407 C coolant. This is a chlorine-free coolant which
does not affect the Earth's ozone layer. R 407 C is nei-
ther a fire hazard nor an explosion risk.
a
d
h

Coolants

Danger!
Environmental hazard!
This unit contains R 407 C coolant. The
coolant must not be allowed to escape
into the atmosphere. R 407 C is a fluori-
nated, chlorine-free greenhouse gas that
has been included in the Kyoto Protocol,
with a GWP of 1653 (GWP = Global
Warming Potential).
Before the appliance is disposed of, the
coolant it contains must be completely
drained into a suitable vessel so that it
can then be recycled or disposed of in
accordance with the regulations.
The relevant work in connection with the
coolant may only be carried out by offi-
cially certified specialists.
Danger!
Risk of injury from freezing as a result
of contact with the R 407 C coolant!
Escaping coolant can cause freezing if
the exit point is touched:
Do not inhale gases or vapours emana-
ting from leaks in the coolant circuit.
Avoid contact with the skin and eyes.
Note
R 407 C coolant presents no danger
during normal use and under normal
conditions. With improper use, however,
it can cause injury and damage.
Operating Manual geoTHERM VWS/VWW 0020051578_01
