4
Loosen counter-nut 2 (one per side) and
adjust register 3 until the desired tension
is obtained.
2
3
Measure distance X between number
4
plate holder support 4 and anvil 5.
5
X
Measure distance X between number
plate holder support 4 and anvil 5.
7
8
6
X
Ensure the distance between chain and
swingarm is that recommended.
10Nm
2
If the distance between chain and
80Nm
3
swingarm is not that recommended pro-
ceed to readjustment.
After completing adjustment, keep register
3 locked and tighten counter-nut 2 (on
each side) to the specified torque.
Tighten the pin to the torque indicated.
EN
58
