4.1.1

Sockets

3 measurement socket 10 A
Measurement socket for the purpose of measurements of di-
rect current up to 10 A.
4 measurement socket COM
Measurement socket common for all the measurement func-
tions.
5 measurement socket VΩTEMPHz%mAμA
Measurement socket for all the measurement functions ex-
cept of 10 A current measurements.
4.1.2

Elements of selection of the measurement function

1 5000 count Liquid Crystal Display with symbolic signs
2 Rotational selector
Selection of function:

Temp – Celsius or Fahrenheit temperature measurement

Hz% – frequency and duty cycle measurement

Ω
measurement and diode testing

– AC and DC voltage measurement
V

OFF – meter off

10A

mA

μA
6 MODE button

Measurement mode selection: Ohm / Diode / Continuity /
Cap, DC / AC, Hz / %Duty
7 RANGE button

Manual range selection
8 HOLD

Data Hold function

Back Light function
CAP – resistance, capacitance and continuity
– AC and DC current measurement up to 10 A
– AC and DC current measurement up to 400 mA
– AC and DC current measurement up to 400 μA
button
