Explanation of Symbols

Warning messages regarding possible risks of accident or injury.
CAUTION
Warning messages regarding possible technical damages.
NOTICE
Additional information on the fitting/application.
INFORMATION
INFORMATION
Please read the Instruction for Use carefully. Please pay special attention to the warning
notice!

1 Single Components

1.1 Scope of Delivery
The 1C61 Triton Vertical Shock is delivered with the following components:
1. 1C61 Triton Vertical Shock foot module (incl. 4X260 Functional Ring*)
2. 2F60 Heel Wedge Kit
3. SL = Spectra-Sock Protective Sock
4. 647G674 Instructions for Use
* Additional versions of the 4X260 Functional Ring can be ordered separately (for selections refer
to Section 4.4.1).
1.2 Accessories • (Fig. 1)
(1) Footshell (includes connection cap)
2C6=*S SlimFootshell
2C6=(Side)(Size) / (Colour)S
Order example: 2C6=L27/4S
Sides
Sizes (cm)
Colours
2C6=*N Normal Footshell
2C6=(Side)(Size) / (Colour)N
Order example: 2C6=L27/4N
Sides
Sizes (cm)
Colours
1.3 Single Components  (Fig. 1; for reordering)
(2) Connection Cap for Footshell (can be ordered individually)
2C20=Slim Connection cap
2C20=(Side)(Size)/(Colour)
Order example: 2C20=L23/4
left (L), right (R)
21 22 23
beige (4), light brown (15)
left (L), right (R)
– – –
beige (4), light brown (15)
24 25 26
24 25 26
27 – –
27 28 29
