To switch ON and OFF the Lawn Mower
Ensure that there is oil in the crakcase and that it is at

the correct level.
Verify if there is gasoline in the fuel tank and if the

fuel valve is opened.
Refuel only with regular unleaded gasoline (no

additives).
Hold on tight the break retractile lever along with

the cable. This engine has manual choke, therefore,
position the accelerator lever in the maximum
position to flood the engine (Fig. 1 - page 50). Position
the acceleration lever in the position indicated by the
choke symbol, according to the following figure.
Slightly pull the engine retractile start rope up to

find resistance, then, pull it abruptly. Repeat the
operation up to the engine works.
Leave the engine heating up for a few minutes and

then position the accelerator cable in the work
position (bunny symbol) according to the indication
in the accelerator cable to initiate the grass cutting.
In order to turn off the engine in an emergency

situation, just release the break lever.
In order to turn the engine off in a normal condition,

perform the work normally with the fuel valve
closed and wait for the fuel from the carburetor be
consumed, following release the break lever.
Front Wheel with Traction System
Some mower models are provided with front wheel
drive. Operate the drive system as described below:
Keep the engine retractile break lever in the

operation position with the engine on (Fig. 1 and 2).
Pull the traction actuation lever fully forward up to

hear a click, only then, release the lever and the
traction system will be activated.
Note:
The average consumption may vary

according to the job requirements and
operator.
Notes:
Do not use the choke when the engine

is hot. If, even hot, the engine does not
start, trigger the choke in order to start.
The engine does not respond when

accelerating without
effort), it increases the rotation when
the machine is submitted to the work
(one must not, in any hypothesis, to
alter the original spring pressure of the
accelerator).
16 mm
S
L
O
W
52 mm
F
A
S
T
Tilt a little the front wheel in order to test the traction

actuation, as soon as you feel it safe regarding the
traction system operation, begin the work.
The wheel speed is proportional to the engine

acceleration; as soon as the traction is activated
gradually accelerate the engine in order to not feel
an impact. In an emergency situation, release the
break lever so that the traction and the engine are
immediately turned off.
load (work
Choke
