TECHNICAL PRESENTATION
Model
Input
Output
Battery type

CONTROL PANEL

LCD DISPLAY
The icon will indicate 2A Charge Rate, which is used for charging the small capacity batteries used in
1
motorcycle, ATV, snowmobile, personal watercraft, garden tractor and golf car.
The icon will indicate 4A Charge Rate, which is used for faster charging of small-to-large capacity
2
automotive, marine, deep cycle and farm tractor batteries.
The icon will appear when selecting the mode of charging in cold state, which means the max
3
charging voltage is 0.2V than usual.
"6V" will appear when selecting the charge for the 6V batteries.
4
"12V" will appear when selecting the charge for the 12V batteries.
5
The icon will indicate the charging process.
6
The numbers or characters will indicate the battery voltage or the error code.
7
MODE SELECTION BUTTON
Press the Mode Selection Button to select one of the 6 charging modes.
Mode 1: 6V 2A (Icon
Mode 2: 6V 2A in the cold state (Icon
Mode 3: 12V 2A (Icon
Mode 4: 12V 2A in the cold state
Mode 5: 12V 4A (Icon
Mode 6: 12V 4A in the cold state (Icon
1 4
+ will appear)
1
+
1 5
+ will appear)
1 3
+ +
2 5
+ will appear)
2
2207762/NO6700
220-240V AC
50/60Hz 0.8A
6V/12V DC max 2A
12V DC max 4A
Lead-Acid, AGM, Gel
3 4
+ will appear)
5
will appear)
3 5
+ + will appear)
