CHAPTER 3

TECHNICAL DATA

TECHNICAL DATA
Mains voltage / Frequency
Absorbed power
Type of protection / Insulation class
Delivery fitting
Maximum flow rate
Maximum head
Maximum depth of immersion
Power cable
Weight (without power cord)
Maximum dimension of pumped solid particles
Maximum temperature of the pumped fluid (in continuous mode)
Maximum number of starts per hour (uniformly distributed)
Minimum priming level (A)*
Minimum suction level (B)* (manual mode)
Start level (C)* (automatic mode)
Stop level (D)* (automatic mode)
(*) These data refer to Fig. 1, Pag. 91. Measurements are expressed in millimetres.
The maximum flow rates given are reached if the pump is used without the check valve supplied.
The pumps of this series are not suitable for table fountains or aquariums. In these cases, it is neces-
sary to use a H07 RN-F cable. If these pumps are used in continuous mode for ponds with fish, it is
necessary to check them at regular intervals of 6 months (if the water contains aggressive substan-
ces). It is also advisable to check the maximum dimension of particles recommended for the pump
and take the necessary measures to prevent the fish from being sucked into the pump.
DPC 150/7 DPC 200/10
230 V ~ 50 Hz 230 V ~ 50 Hz
330 Watt 650 Watt
IP 68 / F IP 68 / F
1 1
1/4"
150 l/min 200 l/min
7 m 10 m
7 m 7 m
10 m H05 RNF 10 m H05 RNF
4,7 Kg 4,8 Kg
5 mm 5 mm
40° C 40° C
30 30
15 mm 15 mm
3 mm 3 mm
140 mm 140 mm
30 mm 30 mm
