Piezas de repuesto

Three/Four-Pump and 100L Melter Left Panel Parts

Item Part
— - - - - - - -
01 - - - - - - -
03 - - - - - - -
04 - - - - - - -
05 - - - - - - -
06 - - - - - - -
07 - - - - - - -
08 - - - - - - -
10 - - - - - - -
11 - - - - - - -
12 - - - - - - -
13 - - - - - - -
14 7400378
15 7400301
7400483
7400762
16
7400319
17 7400482
7400380
18
7104855
19 - - - - - - -
20 - - - - - - -
21 7400369
23 - - - - - - -
24 - - - - - - -
25 - - - - - - -
26 - - - - - - -
27 - - - - - - -
28 - - - - - - -
31 - - - - - - -
NOTE A: Present only on melters with the optional lockout switch.
P/N 7135331A03
See Figure 7-27.
Description
Assembly, electrical, panel, left, three/four-pump,
100L, six hose/gun
S Panel, left, inner, electrical cabinet
S Wireway, 50 x 50 x 330
S Wireway, 25 x 50 x 180
S Wireway, 25 x 50 x 257
S Washer, flat, M3
S Washer, lock, M3
S Nut, acorn, M3
S DIN rail, 35 x 7.5 x 250
S Washer, flat, M5
S Washer, lock, M5
S Nut, hex, M5
S Main switch, 100 A, 3 pole
2
S Kit, filter, fan, 204 mm
S Main contactor, 55 A (400V melters)
S Main contactor, 80 A (240V six hose/gun
melters)
S Main contactor, 95 A (240V eight hose/gun
melters)
S RC suppressor, 110−250 VAC
S Main breaker, 70 A (400V melters)
S Main breaker, 90 A (240V melters)
S Block, distribution, 250 A, 600V
S End stop, terminal
S Switch, lockout (240V melters)
S Panel, left, outer, electrical cabinet
S Washer, flat, regular, M6
S Washer, lock, split, M6
S Nut, hex, M6
S Marker, wire, push on, 16−22 AWG
S Maker, wire, push on, 10−16 AWG
S Screw, pan, recessed, M4 x 16
(qty. 2)
Quantity Note
—
1
1
1
2
11
11
11
1
2
2
2
1
1
1
1
1
1
1
1
4
5
1 A
1
9
9
5
36
29
4
