Technical data

Type
Electric motor
Type
For DC systems
Current
Power consumption
Rating
Protection
Insulation class
Ignition protected
Motor controller
MCV
Transmission
Gears
Gear ratio
Lubrication
Housing
Propeller
Diameter
No. of blades
Profile
Material
Rated thrust
Control circuit
Fuse
Control circuit wires
Extension cable
Thrust-tunnel
Steel model
dimensions
treatment
Plastic model
dimensions
material
Aluminium model
dimensions
material
Weight
[1] S2 '10' min.  Activation time '10' min. continuously or a max. of '10' min. per hour at maximum power.
[2] S2 '5' min.  Activation time '5' min. continuously or max. '5' min per hour at maximum power.
16
020810.02
BOWPRO A serie
BOWA0301
EC Motor
(8VAC-1.2kW)
12 V =
174 A @ 12,0 V
199 A @ 10,5 V
2.1 kW
S2 - 10 min. [1]
MCV30024
+ MVC0301S
1 : 1
ca. 0.024 litre (0.8 fl.oz.)
108 mm (4 1/4")
6
asymmetrical
polyacetal (Delrin ®)
300 N (30 kgf, 66 lbf ) 360 N (36 kgf, 79 lbf ) 360 N (36 kgf, 79 lbf) 420 N (42 kgf, 93 lbf )
O.D. 121 mm,
wall thickness 4.5 mm
blasted, coated with: SikaCor Steel Protect. Suitable for all kinds of protection systems.
I.D. 110 mm, wall
thickness 5 mm
I.D. 110 mm, wall
thickness 5 mm
26 kg (57 lbs)
BOWA0361 BOWA0364
EC Motor
(8VAC-1.2kW)
12 V =
240 A @ 12,0 V
273 A @ 10,5 V
2.9 kW
S2 - 10 min. [1] S2 - 10 min. [1]
IP44
F
Motors conform to CE (2014/30/EU, EMC - EN60945)
No
MCV30024
+ MCV0361S
Bevel gear helical teeth
oilbath, outboard gear oil SAE80W or EP 90
ca. 0.04 litre (1.4 fl.oz.)
bronze
122 mm (4 13/16")
polyacetal (Delrin ®)
Blade type fuse 'ATO' 5 A
2 x 2x 0.5 mm 2 (2 x 2 x AWG20) Twisted pair
5, 10, 15, 20 of 25 m (16' , 33' , 49' , 66, or 82')
O.D. 133 mm, wall thickness 4 mm
I.D. 125 mm, wall thickness 5 mm
glass fibre reinforced polyester
I.D. 125 mm, wall thickness 4 mm
aluminium, 6060 of 6062 (AlMg1SiCu)
26 kg (57 lbs)
vetus® Owner's Manual BOW PRO Series Thrusters
BOWA0421
EC Motor EC Motor
(8VAC-1.2kW) (8VAC-2.7kW)
48 V = 12 V =
61 A @ 48 V 218 A @ 12,0 V
71 A @ 42 V 250 A @ 10,5 V
2.9 kW 2.6 kW
S2 - 10 min. [1]
MCV25048C MCV30024
+ MCV0364S + MCV0421S
1 : 1
6
asymmetrical
26 kg (57 lbs) 26 kg (57 lbs)
