ssembly Plan
Swing Beam ssembly.
1. Position Split-Brackets on 4'' x 4'' x 47-1/2''
(Fig 18).
2. With the help of others, lift -Frame and
Swing Beam ssembly and center onto unit as
shown in (Fig. 18)
3. Secure as shown in (Fig 18a).
Fig. 18a
View from Deck
x 8 (each bracket)
2'' Lag screw
