ASSEMBLY AND INSTALLATION MANUAL
B1 BRAVOMAX A INSTALLATION
B1.1 Before the installation
Warning! Before the installation of BravoMAX A please verify that the water supplied fulfils the requirements
of European drinking water directives 98/83/CE. Check for the compliance of the hydraulic distribution
system and the installation of the filter to local regulations. The manufacturer disclaims all responsibilities for damage
to persons or things caused by improper installation of the filter and/or the installation of the filter in a waterworks
not compliant with local regulations.
BravoMAX A is not equipped, by standard, with any flooding-control system or other devices able to detect, control or
alarm in case of runaway water losses. In case, consider, apart, an adequate anti flooding device.
Do not install BravoMAX A downstream of boilers or in devices involving the transit, inside the filter, of water at higher
than 40°C temperature. Install BravoMAX A upstream of devices to protect. BravoMAX A cannot be used to treat
closed loop water (ex. heating systems water) or any other applications not cited in this manual.
B1.2 Requirements for the place of installation
BravoMAX A must be installed indoor, in an hygienically suitable place, dry and clean, protected from frost, exposure
to sunlight, moisture, atmospheric agent (rain, snow and hail). Do not install BravoMAX A in wells, near drains, or in
smelly places. Do not install where any kind of chemical vapours or gas and fumes may be present. Avoid installation
in tight spaces which cannot allow easy ordinary and extraordinary maintenance. Below the limit values of the allowed
environmental parameters for the BravoMAX A installation:
Ambient temperature (min./max.), °C:
B1.3 Laws, Regulations and Standards
The installation of BravoMAX A must be performed in compliance with local laws, regulations and standards.
B1.4 Instruction for installation
The installation must be performed in accordance with best practice, in line with all the current legislation and the
rating data.
Before installing the filter make sure that the plant fits with the laws or regulations or local recommendations
produced by the office in charge. Before installing the filter, clean pipes and appliances installed upstream of the filter
in order to eliminate foreign bodies which cancause the malfunction of the filter itself. If the level of cleanliness in the
plant is not adequate you should sanitize the plant and the possible storage tanks before the installation of BravoMAX
A. The filter should not be installed between the boiler and safety devices.
The hydraulic distribution system implemented to install devices connected to the water distribution system must be
provided with a system able to ensure the no return of the treated water in the distribution system, and with a
manual or automatic by-pass valve system in order to allow the withdrawal of no treated water interrupting the flow
of treated water.
Warning! Avoid solvents, oils, acidic or caustic substances and detergents to come in contact with the
external plastic and brass part of the device. In case of very strong impact during the transport or the
assembly do not install the device and replace it even in case of no apparent damages to the plastic parts. Limit the
presence of water hammer.
B1.5 Electric checks after installation
When the filter is connected to the power supply the leds (yellow and green) frontally placed on the carter of the filter
light up; the device carry out a test washing; when it is finished the yellow led switches off and the green one stays on.
The filter is working.
After this stage, verify the functioning of the circuit pressing the black button frontally located between the leds, until
the yellow one lights up; the filter carry out a washing; when it is finished the yellow led will flash for two minutes and
then it will switches off. The filter is working and the green led stays on.
BravoMAX A - ENGLISH
5 - 40
MAN136 PAG.E-9
