9 Especificaciones del Sensor
9.8.3 Listado de partes PR-23-M
4
1
2
3
7
5
8
Item
Pcs.
Part No.
1
4
2
1
3
1
PR-9129
4
1
5
1
PR-9120
5
1
PR-9121
6
1
PR-9240
7
6
8
1
9
1
PR-9112
10
1
PR-9126
11
1
PR-9113
12
1
PR-9100
13
1
PR-11101
14
1
PR-10048
15
1
16
1
PR-10005
16
1
PR-10005-EC
17
6
6
9
6
12
13
10
14
11
Description
Screw M5x60 DIN 7991 A4
PR-23-M endplate
PR-03/23-M protection cover
Screw DIN 912 M4x10 A4
PR-03/23-M-PV-R05 flow cell (PVDF)
PR-03/23-M-TF-R05 flow cell (PTFE)
O-ring seal 19.2 x 3 Kalrez 4079
Screw M4 x 20 DIN 7991 A4
PR-03/23-M headring (PVDF)
O-ring seal 30.3 x 2.4 FPM
Sapphire plate for PR-03/23-M
O-ring seal 37.3 x 3 FPM
Sensor support
PR-23-M head
68x3 O-ring
Alignment pin
PR-23 base
PR-23-EC base
Screw M5x12 DIN 912 A2
Locking spacer M5
15
16
17
20
19
18
21
24
35
27
Item
Pcs.
Part No.
Description
18
1
PR-10036
PR-23 compact sensor CORE module
19
1
PR-9011
Thermal conductor
*
1
PR-9010
Disc spring set
20
2
Disc spring
21
1
Disc spring holder
22
6
Screw DIN 912 M5x12 A2
23
1
PR-10103
Sensor processor card
24
4
Screw M3x6 DIN 912 A2
25
4
Screw M3x6 DIN 912 A2
26
1
PR-10300
Bus terminator card
27
1
PR-9108
Dryer for PR-23
28
1
O-ring seal 24 x 2
29
1
PR-10000
PR-23 cover
29
1
PR-10000-EC
PR-23-EC cover
30
4
Screw M4x30 DIN 912 A4
31
1
PR-10002
O-ring seal 83x3
32
1
Cable gland M16x1.5
33
1
PR-23-M nameplate
34
4
Screw M4x8 DIN 964 A4
35
1
O-ring seal 89.5 x 3
115
22
25
23
26
28
29
31
30
33
32
34
