STARTING UP AND PROGRAMMING
5

CHECKING IMPACT FORCE


The control board must be programmed in a
manner which respects the values indicated in
standard EN 12453. All measurements must be
made in line with the method described in
standard EN 12445.
• The Standard indicates that dynamic force must be
less than 400N.
• Fd < 400N in spaces between 50 mm and 500 mm
• Fd < 1400N in spaces > 500mm
6

STARTING UP

Final checks

Following installation and programming, start up the
operator and check the devices installed.
1 Check the correct operation of the key commands
(pushbutton and wall key, remote control).

See "Operation modes" on page 37.
2 Check the correct operation of the safety devices
(photocells).

See "A- Detection by the additional safety device
(photocell)" on page 39.
3 Place an obstacle and make the door collide with it
in order to check operation in the event of collision.

See "B- Direct detection (operator sensitivity)"
on page 39.

If the system does not work correctly, find out
why and
"Troubleshooting" on page 63).
62
Installation guide
put it right (see
Measure the impact force and compare it to the
values indicated in Standard EN12453:2000. If the
measured values are higher than in the Standard,
suitably adjust the sensitivities, slowdown distances and
speeds:
• Sensitivity in opening: menu 4
• Sensitivity in closing: menu 5
• Slowdown distance in closing: menu 8
• Opening speed: menu 11
• Closing speed: menu 12

User training

1 Train the user with regards to using and maintaining
the facility, and provide
instructions for use.
2 Signpost the door, showing that it opens
automatically and indicating how to operate it
manually.
operation is using the remote control.
section
him/her with
Where appropriate, indicate
the
that
