Carefully insert the appliance into the worktop cut-
2.
out.
→ Fig.
32
Screwing the retaining clips in place
Screw the enclosed retaining clips onto the work-
▶
top and carefully onto the appliance.
Ensure that the hob is at the same height as the
‒
worktop and the appliance does not slip.
Do not use an electric screwdriver.
‒
→ Fig.
33
Securing the adapter
Hold the adapter at the central holder and use the
1.
side holders to slide it towards the unit's back
panel in the base unit, then affix it.
→ Fig.
34
If required, also use screws to secure it.
2.
→ Fig.
35
Preparing the unit for circulating-air mode with a
circulating-air duct
If required, remove the unit's back wall.
1.
Observe the relevant dimensions when combining
2.
with the flat duct elbow for the cut-out in the back
wall.
→ Fig.
36
In circulating-air mode, establish an air outlet in
3.
the unit's plinth.
Provide a minimum air outlet cross-section of
‒
approx. 400 cm².
Make the outlet opening in the base panel as
‒
large as possible in order to keep draughts and
noise to a minimum.
Make the outlet opening by shortening the
‒
plinth or by using suitable ventilation grilles or a
lamellar plinth.
To guarantee that the appliance works correctly,
4.
ventilate the hob appropriately via an air outlet
with a minimum cross-section of 200 cm² in the
base unit.
After making the cut-outs, remove any shavings.
5.
Seal the cut surfaces so that they are heat-resist-
6.
ant and waterproof.
→ Fig.
24
Installing the appliance for air recirculation mode
with circulating-air duct
For circulating-air mode, use the seal, the circulat-
1.
ing-air duct, the diffuser and the odour filter.
Observe the dimensions for the different flat duct
2.
bends. → Page 21
Securing the seal
Secure the enclosed seal on the flat duct elbow at
▶
a maximum of 5 mm from the edge.
→ Fig.
37
Inserting the flat duct elbow
Insert the flat duct elbow into the outlet opening
▶
on the rear of the appliance.
→ Fig.
38
Inserting the appliance into the worktop cut-out
Ensure that the connection cable is connected to
1.
the appliance.
Carefully insert the appliance into the worktop cut-
2.
out.
→ Fig.
39
24
Establishing the pipework between the appliance and
the diffuser
Connect the components of the circulating-air duct
1.
to each other.
Secure the flat duct pipe connector by enga-
‒
ging it in place.
For an additional fixing, screw the flat duct pipe
‒
connector together using 4 x PT 4x8 mm
screws for plastic.
→ Fig.
40
Connect the circulating-air duct to the flat duct el-
2.
bow on the rear of the hob.
→ Fig.
41
Connect the diffuser to the circulating-air duct.
3.
→ Fig.
42
Screwing the retaining clips in place
Screw the enclosed retaining clips onto the work-
▶
top and carefully onto the appliance.
Ensure that the hob is at the same height as the
‒
worktop and the appliance does not slip.
Do not use an electric screwdriver.
‒
→ Fig.
43
Preparing the unit for air extraction mode
If required, remove the unit's back wall.
1.
Observe the relevant dimensions when combining
2.
with a flat duct elbow for the cut-out in the back
wall.
→ Fig.
44
After making the cut-outs, remove any shavings.
3.
Seal the cut surfaces so that they are heat-resist-
4.
ant and waterproof.
→ Fig.
45
Install the appliance for air extraction mode
For air extraction mode, use the seal and the
1.
acoustics filters.
Observe the instructions for the exhaust air pipe.
2.
→ Page 22
Securing the seal
Secure the enclosed seal on the flat duct elbow at
▶
a maximum of 5 mm from the edge.
→ Fig.
37
Establishing the piping
Insert the flat duct elbow into the outlet opening
1.
on the rear of the appliance.
→ Fig.
38
If required, install additional piping elements.
2.
Inserting the appliance into the worktop cut-out
Ensure that the connection cable is connected to
1.
the appliance.
Carefully insert the appliance into the worktop cut-
2.
out.
→ Fig.
39
Screwing the retaining clips in place
Screw the enclosed retaining clips onto the work-
▶
top and carefully onto the appliance.
Ensure that the hob is at the same height as the
‒
worktop and the appliance does not slip.
Do not use an electric screwdriver.
‒
→ Fig.
33
Connecting the exhaust air pipe
Secure the exhaust air pipe to the flat duct bend.
1.
Establish the connection to the exhaust air open-
2.
ing.
Seal the joints appropriately.
3.
