Spraying Troubleshooting -

If the spray pattern becomes distorted or stops completely while the gun is triggered, follow these steps.
Do not attempt to unclog or clean the tip with your
finger. High pressure fluid can cause injection injury.
IMPORTAnT: Do not use a needle or other sharp pointed
instrument to clean the tip. The hard tungsten carbide can chip.
1. Release the trigger and lock the gun trigger (see page 7).
Rotate the reversible tip arrow 180º clockwise as shown
so that the point of the arrow is toward the rear of the gun
(CLEAN position).
Under pressure, the spray tip may be very difficult
to turn. Turn the PRIME/SPRAy knob to PRIME and
trigger the gun. This will relieve pressure and the tip
will turn more easily.
2. Turn the PRIME/SPRAY knob to SPRAY - MINIMUM
PRESSURE.
3. Unlock the trigger and squeeze the trigger, pointing the
gun at a scrap piece of wood or cardboard. This allows
pressure in the spray hose to blow out the obstruction.
When the nozzle is clean, material will come out in a
straight, high pressure stream.
If material still will not spray from the spray
tip, follow the Cleaning the Spray Gun Filter
instructions, page 12.
4. Release the trigger and lock the gun trigger (see page 7).
Reverse the tip counterclockwise as shown so the arrow
points forward again (SPRAY position). Unlock the trigger
and resume spraying.

unclogging the Spray Tip

CLEAN
CLEAN CLEAN ROLL ROLL
SPRAY
11
Trigger locked
(see page 7)
Trigger locked
(see page 7)
