7.2 Technical Data AKM2G-2x Series

7.2.1 Technical Data AKM2G-21

U Parameter
N
Max. Rated Equivalent Line
Voltage
Max. Continuous Torque for ∆ T
winding = 100°C (1)(2)(4)
Max. Continuous Current for ∆ T
winding = 100°C (1)(2)(4)
Max. Continuous Torque for ∆ T
winding = 60°C (2)(4)
Max. mechanical speed (5)
Peak Torque (1)(2)(4)
Peak Current
120 Rated Torque (speed) (1)(2)(4)
V AC
Rated Speed
Rated Power (speed) (1)(2)(4)
240 Rated Torque (speed) (1)(2)(4)
V AC
Rated Speed
Rated Power (speed) (1)(2)(4)
400 Rated Torque (speed) (1)(2)(4)
V AC
Rated Speed
Rated Power (speed) (1)(2)(4)
480 Rated Torque (speed) (1)(2)(4)
V AC
Rated Speed
Rated Power (speed) (1)(2)(4)
AKM2G Instructions | 7 Technical Data
Tolerance Symbol
Electrical data
Max V bus
Nom Tmc
Nom Imc
Nom Tmc
Nom Nmax
Nom Tp
Nom Ip
Trtd
Nrtd
Prtd
Trtd
Nrtd
Prtd
Trtd
Nrtd
Prtd
Trtd
Nrtd
Prtd
Kollmorgen | kdn.kollmorgen.com | August 2020
Units AKM2G
21D 21E
V ac 480 240
Nm 0.636 0.642
ib-in 5.62 5.68
Arms 2.17 2.73
Nm 0.494 0.498
lb-in 4.37 4.41
rpm 8000 8000
Nm 1.78 1.79
lb-in 15.7 15.8
Arms 8.66 10.9
Nm 0.583 0.568
lb-in 5.16 5.02
rpm 4800 6200
kW 0.293 0.369
Hp 0.393 0.494
Nm 0.534 0.534
lb-in 4.73 4.73
rpm 8000 8000
kW 0.448 0.448
Hp 0.600 0.600
Nm 0.525
lb-in 4.64
rpm 8000
kW 0.439
Hp 0.589
Nm 0.520
lb-in 4.60
rpm 8000
kW 0.435
Hp 0.584
21G
120
0.649
5.75
4.18
0.503
4.45
8000
1.79
15.9
16.7
0.545
4.82
8000
0.456
0.612
173
