12 EN – Quick installation and start-up guide

Connect the control cables

See figure H. It shows an example with one analog signal cable and one digital signal
cable. Make the connections according to the macro in use. The default connections
of the ABB standard macro are shown in section
1. Remove the front cover. See section
Connecting an analog signal cable:
2. Cut an adequate hole into the rubber grommet and slide the grommet onto the
cable. Slide the cable through a hole of the bottom plate and attach the grommet
to the hole.
EN
3. Ground the outer shield of the cable 360 degrees under the grounding clamp.
Keep the cable unstripped as close to the terminals of the control board as
DE
possible. Ground also the pair-cable shields and grounding wire at the SCR1
terminal.
ES
4. Route the cable as shown in the figure.
FI
5. Connect the conductors to the appropriate terminals of the control board and
tighten to 0.5...0.6 N·m.
FR
6. Tie all control cables to the provided cable tie mounts.
IT
NL
RU
SV
TR
ZH
xx
xx
Default I/O connections
Connect the power cables
on page 13.
on page 11.
