GB
OPERATION
OPENING DOOR WITH C10 MAGNETIC KEY
Point the tip of the electronic
key towards the magnetic
sensor on the externa plate at
a distance of 2 cm and briefl y
press the WHITE button.
The buzzer on the sensor-
display board first emits a
single "beep" and, after a
pause of about two seconds, a
short melody to indicate that
the opening of the door and
of the deadbolts.
The display lights up and displays the door opening animation,
pausing on the open position image. The display stays lit up for
ca. fi ve seconds. The electronic card keeps the lok open until the
door. Is closed manually (as detected by a micro-switch) and then
procced with the defi nitive closting.
A brief melody indicates that the door is closed.
OPENING DOOR WITH KEYPAD
Enter the pre-programmed, 4-digit max.
security code (1 to 9999).
After a brief pause the keypad sends the
coded open command to the electronic
card.
The electronic card, buzzer and display
behave as described above when unlocking
the door with the electronic key.
The electronic door lock also controls the
radio-controlled alarm system.
ALARM SYSTEM ON
Point the tip of the electronic key towards the magnetic sensor
on the external
plate at a distance of 2 cm and briefl y press the REDDER button
on the key.
The buzzer on the sensor panel emits a double "beep" and the
electronic control board broadcasts the activation command to
the alarm system.
The display indicates that the alarm system is activated by animating
the movement of the "eyes icon" and fi xing them open.
The indicator led on the sensor panel fl ashes every two seconds
while the system is activated.
This will set the S10 siren off with an approx. 60-second delay
(exit time).
42
MAGNETIC
SENSOR
