KBM80U
Viseo Touch Pad
Gear switch
QuickIN Max
Tool holder
Application tool
Button for cooling lubricant
supply
Stop motor button
Coolant container
Capstan handle
Magnetic foot
Main switch
Clamping lever
Guard protecting against chippings
Button for starting the drill
motor in anticlockwise rota-
tion direction (inch mode)
Button for starting the drill
motor in clockwise rotation
direction
Button for speed reduction
