Sistema De Gas 120V, 208V - Alto-Shaam COMBITHERM CT PRoformance Serie Manual De Mantenimiento Técnico

120V
6-10, 7-20, 10-10, 10-20
120V
20-10, 20-20

Sistema de Gas 120V, 208V

208-240V 1PH & 3PH
6-10, 7-20, 10-10, 10-20
1PH & 3PH
20
142 • MN-35949 • Rev 05 • 02/17 • Series Combitherm® CT PROformance™ y CT Classic™ Manual Técnico – Diagramas de cableado 77623
5015355-7W
TERM TERM
# WI-STOCK T-CONN. FROM LOC TO LOC
200 WI-33478 CR-34783 TB33 6 IGNTR LWR
201 WI-33777 CR-34783 TB-27 6 IGNTR N
206 WI-33777 CR-33509 31 CB-X10 8
N7
207 WI-33777 CR-33509 N7 32 CB-X10 7
204 WI-33777 CR-33509 N7 11 TB27 8
5015353-7W
TERM TERM
# WI-STOCK T-CONN. FROM LOC TO LOC
200 WI-33478 CR-34783 TB33 6 IGNTR LWR
201 WI-33777 CR-34783 TB-27 6 IGNTR N
206 WI-33777 CR-33509 N7 31 CB-X10 8
207 WI-33777 CR-33509 N7 32 CB-X10 7
204 WI-33777 CR-33509 N7 11 TB27 8
5015356-5W
TERM TERM
WI-STOC
# T-CONN. FROM LOC TO LOC
K
200 WI-33478 CR-34783 TB33 6 IGNTR LWR
201 WI-33777 CR-34783 TB27 6 IGNTR N
202 WI-33478 CR-34783 TB33 5 IGNTR UPPR
203 WI-33777 CR-34783 TB27 10 IGNTR N
204 WI-33777 CR-34783 TB27 8 N7 11
205 WI-33777 CR-33509 N7 21 N7 11
206 WI-33777 CR-33509 N7 31 CB-X10 8
207 WI-33777 CR-33509 N7 32 CB-X10 7
5017494-1W
TERM TERM
# WI-STOCK T-CONN. FROM LOC TO LOC
208 WI-33478 CR-33509 BA-36655 2 IGNTR LWR
5017495-1W
TERM TERM
# WI-STOCK T-CONN. FROM LOC TO LOC
208 WI-33478 CR-33509 BA-36655 2 IGNTR LWR
209 WI-33478 CR-33509 BA-36655 2 IGNTR UPPR
L-CONN.
CR-33509
CR-36869
CR-34783
CR-34783
CR-34783
L-CONN.
CR-33509
CR-36869
CR-34783
CR-34783
CR-34783
L-CONN.
CR-33509
CR-36869
CR-33509
CR-36869
CR-34774
CR-33509
CR-34783
CR-34783
L-CONN.
CR-36869
L-CONN.
CR-36869
CR-36869
    


6.10 UP-TO 20.20 120V/208V GAS MODEL
  
AFT
77623
 07/27/15 6 OF 42
