Determining and setting the speed

9.2.1

Determining the cutting speed

There are 2 speed levels in the RPG drives. It is recommended that you work exclusively with speed level 1.
RPG ONE and RPG 1.5: disabled speed level 2 upon delivery.
TYPE OF MAcHINE
RPG ONE
RPG ONE Cordless
RPG 1.5
RPG 1.5 Cordless
RPG 2.5
RPG 2.5 Cordless
9.2.2

Setting speed with RPG Electric machines

NOTE!
The speed level can be pre-installed using the speed regulator (1) in the RPG Electric. The outer diameter of the tube can be
adjusted precisely using the thumb wheel (2):
SPEED REGULATOR (1) LEVEL cODES
Level 1
Level 2
Increasing speed:
X Increase speed using thumb wheel (2).
Decreasing speed:
X Decrease speed using thumb wheel (2).
STANDARD VALUES FOR THE
REVOLUTIONS PER MINUTE (N)
[Type of machine]
RPG ONE
RPG ONE
RPG ONE
RPG ONE
RPG 1.5
RPG 1.5
RPG 1.5
72
ORBITALUM TOOLS GmbH D-78224 Singen www.orbitalum.com
SPEED RANGE LEVEL 1
[MIN ]
–1
145 - 380
0 - 500
145 - 380
0 - 500
9 - 52
0 - 29
The chip removal characteristic may be influenced by the speed.
9 - 52 min
–1
27 - 153 min
–1
TUBE OD
[mm]
3,18
6,35
12,70
25,40
3,18
6,35
12,70
SPEED RANGE LEVEL 2
[MIN ]
–1
disabled
disabled
disabled
disabled
27 - 153
0 - 100
1
FINE­TUNING OF THE THUMB WHEEL
SPEED REGULATOR (2)
[inch]
0.125
0.250
0.500
1.000
0.125
0.250
0.500
[REV. 20190314] OC_RPG_S_BA_790036765_00__INH-02_EN
RPG ONE, RPG 1.5, RPG 2.5
2
[Level]
3
2
1
1
3
2
1
