Input terminals

The terminal and socket connections of your LCR meter are described in the table
below.
To avoid damaging this instrument, do not exceed the input limit. Do not
WARNING
apply voltage to input terminals. Discharge the capacitor before testing.
Table 1-8 Input terminal/socket connections
Input terminal/
Description
socket
+
Positive terminal/component socket
-
Negative terminal/component socket
GUARD
Guard terminal/component socket
