DIP SWITCH SeTuP
Before you install the camera, you should set the DIP
switches to configure the camera ID, communication
protocol.
Camera ID Setup
❖
ON
ON
1
2
3
4
•
ID number of camera is set using binary number.
The example is shown bellow.
Pin
1
ID Value
1
2
ex) ID=5
on
off
ex) ID=10
off
on
•
The range of ID is 0~255. Factory default of
Camera ID is 1.
•
If you want to control a certain camera, you must
match the camera ID with Cam ID setting of DVR or
Controller.
5
6
7
8
6
7
4
8
16
32
64 128
on
off
off
off
off
off
on
off
off
off
Communication Protocol Setup
❖
ON
ON
1
•
Select the appropriate Protocol with DIP switch
combination.
Pin1
OFF
ON
OFF
ON
•
If you set the protocol as Auto Protocol, camera will
automatically recognize the kind of Protocol.
•
If you want to control using DVR or system keyboard, their
protocol must be identical to camera. Otherwise, you can
not control the camera.
•
If you changed camera protocol by changing DIP S/W, the
change will be effective after you reboot the camera.
•
Factory default of protocol is "Auto" Protocol
Communication baud rate Setup
❖
ON
ON
1
•
Select the appropriate Baud rate with DIP switch
8
combination.
off
Pin
off
OFF
ON
OFF
ON
OFF
•
Factory default of Baud rate is "9600 BPS"
Installation
2
3
4
5
6
7
Switch State
Pin
Pin
Pin
OFF
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
2
3
4
5
6
7
Switch State
Pin6
Pin7
OFF
OFF
OFF
OFF
ON
OFF
ON
OFF
OFF
ON
8
Protocol
Auto Protocol
PELCO-D
PELCO-P
SAMSUNG
8
Protocol
2400 BPS
4800 BPS
9600 BPS
19200 BPS
38400 BPS
English – 11
