4 0 | Operating instructions | OBD 1100 |
MIL to illuminate when the
engine is running .
• MIL ON indicates that the
Malfunction Indicator Lamp
should be ON .
• MIL OFF indicates that the
Malfunction Indicator Lamp
should be OFF .

I / M Monitors (Emissions)

Inspection / Maintenance
Monitors provide a snapshot
of the Emission System opera-
tions by indicating that the
I / M Monitors are Ready or Not
Ready . For an I / M Monitor to
be Ready, the vehicle must have
completed a drive cycle (been
driven long enough under proper
conditions to have completed a
drive cycle) . A Monitor must be
listed as Ready to pass an emis-
sions test . If an I / M Monitor is
Not Ready, it is because a drive
cycle has not completed .
The Tool will indicate Ready
(ok), Not Ready (inc), or Not
Applicable (n/a) for each I / M
Monitor . The Tool supports the
following I / M Monitors:
579682 REV A | 03.2017
Monitor
Monit Falha Igni
Monit . Sist Comb
Comp . Compo-
nente
Monit . Catalis .
Htd Catalyst
Monit Sist Evap
Sist . De Ar Sec .
Monit A/C Refrig
Monit . Sens Oxig
Aquec Sens Oxig
Moni Sis EGR/VVT
NMHC Cat Mon
Monit Tratam NOx Nitrogen Oxide Treatment
Mon Impuls Pres
Sens Exaust Gas
Mon Filtro PM
This is a complete list of I / M
Monitors supported by the Tool .
The number of Monitors read
by the Tool from your vehicle
may vary . A diesel vehicle, for
example, does not have an
Oxygen Sensor Monitor . As a
result, there will be no Oxygen
Sensor Monitor status for a die-
sel vehicle .
Two types of I / M Monitors
tests are:
Bosch Automotive Service Solutions
Expanded Name
Misfire Monitor
Fuel System Monitor
Comprehensive Compo-
nents Monitor
Catalyst Monitor
Heated Catalyst Monitor
Evaporative System Mon-
itor
Secondary Air System
Monitor
Air Conditioning Refriger-
ant Monitor
Oxygen Sensor Monitor
Oxygen Sensor Heater
Monitor
Exhaust Gas Recircula-
tion or Variable Valve Tim-
ing Monitor
Non-Methane Hydrocar-
bon Catalyst
Boost Pressure Monitor
Exhaust Gas Sensor
Particulate Matter Filter
