1. Select the input box "Calibration" in the window
"Program settings / maintenance".
Abb. 16: Program window "Calibration"
 Dialog box is opened to enter password.
Abb. 17: Password dialog box
2. Enter the password.
i
Password = admin.
3. Select <F3> or <enter>:
 Program window "Calibration" is opened.
4. Select wheel alignment test.
Abb. 18: Program window "Calibration"
|
1 690 706 113 2017-10-11
5. Program window "Wheel alignment test" is opened.
Abb. 19: Measurement board recognition
i
Test the message display until all measurement
boards show colored lines:
 Colored lines mean that the cameras can recogni-
ze the measurement boards.
 Otherwise the measurement boards are shown in
grey.
6. Align camera beam manually, electrically or automa-
tically until the measurement boards are recognized.
7. Select for mechanical and electrical align-
ment:
 Program switches back to main menu.
5.2.3 Manual alignment
1. Open the lock of the camera beam on the post.
2. Push camera beam in desired position.
3. Tighten the lock of the camera beam.
!
The camera beam must stop in the guide rail to pre-
vent it from falling.
5.2.4 Electrical alignment
¶
The camera beam is placed in the desired position
by pressing the button on the trolley.
Abb. 20: Height adjustment key
1 Lifting
O Stop
2 Lowering
5.2.5 Automatic alignment
i
The camera beam is automatically placed in the desi-
red position within the program sequence.
