domestic electric installation) and have it put into
DE
operation by a qualified electrician.
EN
– Where technically possible and legally
permissible, the electric installation must be
FR
dimensioned in such a way that the maximum
nominal power of the electrical socket used is
IT
available for charging the vehicle.
ES
– In order to make full use of the charger and to
ensure fast vehicle charging, use either NEMA
PT
electrical sockets with the highest possible
NL
current rating appropriate for the power plug
or industrial electrical outlets according to
SV
IEC 60309.
FI – When charging the high-voltage battery via the
household electrical outlet/industrial electrical
DA
outlet, the electrical installation may be loaded to
its maximum capacity. Porsche recommends that
NO
electrical installations used for charging be
EL
checked regularly by a qualified electrician.
Ask a qualified electrician which inspection
CZ
intervals are appropriate for your installation.
HU – On delivery, the charging current is automatically
limited to prevent overheating of the electrical
PL
installation. Get a qualified electrician to
commission the charger and set the charging
HR
current limit in accordance with the domestic
SR
installation.
f Refer to chapter "Charging Current Limiting"
SK
on page 29.
SL

Intended Purpose

ET
Charger for mode 2 charging used to charge vehicles
LT
with high-voltage batteries, which meet the
generally applicable standards and directives for
LV
electric vehicles.
RO
BG
MK
24

Key to Pictograms

Depending on the country, various pictograms may
be attached to the charger.
Operate the charger within
a temperature range from -30 °C
to +50 °C.
The charger should not be
operated at altitudes of more than
4,000 m above sea level.
The charger is equipped with
a non-switched ground lead.
The charger is equipped with
a switched ground lead.
Dispose of the charger in
compliance with all applicable
disposal regulations.
Do not use extension cables
or cable reels.
Do not use (travel) adapters.
Do not use multi-outlet power
strips.
Do not use a charging cable with
faulty electronics or connecting
lines.
Risk of electric shock due to
improper use.
Observe the operating instructions
provided, particularly the warnings
and safety instructions.
The surface of the charger can
become very hot.
Do not operate the charger in
non-earthed mains supply
systems (e.g. IT networks).
Only operate the charger in
earthed mains supply systems.
Only operate the charger in
single-phase networks.
