6.3

Assembling the product

This product may be operated with Erbe APC applicators only.
Alternatively, this product can also be operated with Erbe HF
electrodes (shaft diameter: 4 mm). If you want to operate this
product with HF electrodes from another manufacturer, please
observe the Safety instructions chapter.
1. Screw an Erbe APC applicator on the APC handle or insert an
Erbe HF electrode into the APC handle.
6.4

Connecting the product

Connection to an APC 2:
After connecting this product to an APC 2, all required operating
parameters are automatically set on the VIO electrosurgical unit.
If you have called up the basic program, the default values spec-
ified at the factory for the product are set. If you have called up
an individual program, the values of this program are set.
1. Screw the argon gas connection of the handle into the argon
receptacle of the APC unit. Erbe recommends using the ad-
ditional membrane filter, Art. No. 20132-059.
2. Insert the HF connector of the handle into the multifunction-
al receptacle of the APC unit.
3. Make sure that the handle of the VIO electrosurgical unit was
detected and the desired operating parameters are set.
4. Only when using an HF electrode: Switch off the argon flow
to the electrosurgical unit (argon flow = 0 l/min.) otherwise,
an error (tube obstruction) is reported when activating the
handle of the electrosurgical unit.
Connection to an APC 300:
After connecting this product to an APC 300, the gas flow is au-
tomatically set on the APC 300. If you have called up program 0,
the default value specified at the factory for the product is set.
28
