/ 700 - TECHNICAL DATA
MODELLO
MODEL
FTBG74A...
FTBG77A...
FTBG74T...
FTBG77T...
INFORMATION ON NEW GAS DUTCH The appliance was configured for
the appliance category K (I2K) and is suitable for the use of G and G+
distribution gases according to the specifications as included in the NTA
8837:2012 Annex D with a Wobbe index of 43.46 – 45.3 MJ/m3 (dry, 0°C,
upper value) or 41.23 – 42.98 (dry, 15°C, upper value).This appliance can
moreover be converted and/or be calibrated for the appliance category E
(I2E). This therefore implies that the appliance "is suitable for G+ gas and H
gas or is demonstrably suitable for G+ gas and can demonstrably be made
suitable for H gas" within the meaning of the "Dutch Decree of 10 May 2016
regarding amendment of the Dutch Gas Appliances Decree and the Dutch
Commodities (Administrative Fines) Act in connection with the changing com-
position of gas in the Netherlands as well as technical amendment of some
other decrees.
1. I diametri degli ugelli sono espressi in 1/100mm – The diameter of the
nozzles are indicated in 1/100mm - Le diamètres des gicleur sont exprimés
en 1/100mm - Diameter der Düsen ist in 1/100mm angegeben – Los diámet-
ros de las boquillas se indican en 1/100mm.
2. RDA: Regolazione dell'aria primaria; Regulation of primari air; Réglage
del'air primaire; Primärlufteinstellung; Regulación de la entrada del aire.
THE PRESENT MANUAL IS PROPERTY OF THE MANUF ACTURER. ANY REPRODUCTION, EVEN P ARTIAL, IS PROHIBITED.
IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA.
Piano
(cm)
Surface
(cm)
SU ARMADIO / ON CABINET
35x57x1,5
65x57x1,5
35x57x1,5
65x57x1,5
Bruciatori
gas 7 kW
Gas burners
7 kW
1
2
TOP
1
2
- 2 -
Attacco Alim.
gas Ø '' (kW)
Gas El.
coupling supply
Ø '' (kW)
-
1/2''
1/2'' -
-
1/2''
1/2'' -
Peso
(kg)
Weight
(kg)
63
97
43
75
