(1)
(2)
Hold on to the pump when inserting the tube cassette. Use the grip edge (4)
at the bottom of the device to ensure the tube cassette is inserted properly
with one hand. Hold the tube cassette (2) as depicted in Fig. 5-4 "Inserting
the tube cassette".
7. Slide your fingers underneath the bottom of the device up behind the grip
edge (4) and hold on to the pump at the same time while using thumb and
hand to insert the tube cassette until it snaps into place. The front of the tube
cassette (3) must be flush with the device front. To remove cassette, press 1x
on the triangle pictogram on the front of the cassette. Part of the tube cas-
sette pops out and the cassette can then be removed.
8. Close the tube clamps. Connect the corresponding fluid bags (see chapter 5.5
"Connecting Fluid Bags").
9. Suspend fluid bags 0.7 to 1.0 m above the device.
10. Select joint type. Press the respective function field on the touch panel to se-
lect the corresponding type of joint.
Fig. 5-4 Inserting the tube cassette
(1) Cassette slot
Tube cassette
(2)
Front of tube cassette
(3)
Grip edge from underneath
(4)
(4)
(3)
Operating the Device
19
EN
