The SP-20 can pair and transmit with the host under the wireless coexistence
environment, but other wireless device may still interface with pairing and tran-
smission between the host and the SP-20 device under uncertain environment. If
the host and the SP-20 display inconsistent, you may need to change the
environment.

4.4.4 Data Management

The user can go to our website to download the corresponding PC Software "Oxi-
meter Data Manager" for this oximeter with the link:
http://www.creative-sz.com/downloads
With the computer installed this PC software, you can upload the data stored in
the oximeter to your PC via wireless or data cable .
It's convenient for user to review the data records and statistical result, aa well as
archive patients' data.

5 Technical Specifications

A. Display Panel: 3.5 inch color TFT LCD;
B. Power Supply:
Internal power supply: 2000mAh lithium battery
AC power adapter: 5VDC/1A,
Working current: ≤180mA
Input power for AC power adapter: <15VA
The typical continuous operation time of the battery: 18 hours (when screen
display is automatically off and bluetooth function is disabled).
The typical service life of the battery: 5 years.
C. SpO Measurement
2
Transducer: dual-wavelength LED sensor with wavelength:
Red light: 663 nm, Infrared light: 890 nm.
Maximal average optical output power: ≤ 2mW
Display range: 0~100%
Measuring accuracy: ARMS value (defined in ISO 80601-2-61) is not greater
than 3% for SpO
SpO low alert limit setting range: 50%~99%
2
The device is calibrated to display functional oxygen saturation.
The functional tester cannot be used to assess the accuracy of the
SpO probe or the device.
2
D. Pulse Rate Measurement
Display and measuring range: 30bpm~250bpm
Accuracy: ±2bpm or ±2% (whichever is greater)
E. Perfusion Index Display
Range: 0.2%~20%
F. Temperature Measurement
Measuring range: 32.0°C~43.0°C
range from 70% to 100%.
2
