GENERAL DESCRIPTION. TECHNICAL CHARACTERISTICS.

The GALAXY 3000 GE MV VRD are electronic technology appliances (INVERTER) designed for use as a
continuous current source for coated electrode and TIG DC welding process.
High-Performance professional use for "OFF SHORE" outdoor applications with a high portability. The
basic characteristics of this line are as follows:
 Heavy Duty 300 A / 40%; 200 A/100 %.

Off Shore Portable (23 Kg). Remote control.

Welding with any type of electrode (1.5 ÷ 6.0 mm).

Multivoltage of automatic adaptation.
 Three phase: 208/220/230/240/380/400/415V - 450 Vmax.
 Single phase - Two-phase 208/220/230 V

Digital V-I as standard.

Connectable to low quality mains supply and electrical generating sets.

A wide voltage drops margin in welding cables.
 VRD: Security no-load voltage for dangerous spaces (Voltage Reducing Device).
 TIG welding mode by Lift-Arc.
TECHNICAL CHARACTERISTICS
Input voltage (Phases, U1)
Maximum supply voltage - U1 max.
Mains voltage frequency
Maximum primary intensity - I1max 3ph 230/400V
Primary effective intensity - I1eff 3ph 230/400V
Maximum effective power 3ph 400V
Overvoltage protection.
Suitable for generator
No-load voltage U20
Voltage Reducing Device VRD (U20R)
Adjustment margin I2 MMA (3 Ph)
Rated intensity I2 100% (3Ph)
Adjustment margin I2 MMA (1 Ph)
M.M.A.
HOT START function (Arc-striking aid).
ARC FORCE function (ARC FORCE)
Antisticking function (ANTISTICKING).
No-load voltage U20
Reduced security no-load voltage (UR)
Adjustment margin (I2min. – I2max.), supply 3ph
T.I.G.
Lift-Arc (soft striking)
Remote control of the welding current.
Remote control detection system.
Voltage change system.
Voltmeter - Ammeter
Digital dial function.
IP mechanical protection class
Welding cable connectors
Thermal insulation grade.
Dimensions W x H x L (mm)
Weight (kg).
GALAXY 3000 GE MV VRD
DATA ACCORDING TO STANDARD EN-60974-1
NEVER USE THESE WELDING MACHINES TO DEFROST TUBES.
GALAXY 3000 GE MV VRD
Ref. 4400000
1 Ph. 208/220/230 V
3 Ph. 208/220/230/380/400 /415V
1 Ph 255V – 3Ph 450 V
50/60 Hz
49/25 A max.
31/16 A max.
22/11 KVA
YES
YES
90 V
SI (10 V)
12 ÷ 300 A / 40%
200 A/ 100%
12 ÷ 200 A / 60%
YES
YES
YES
90 V
10 V
12  300 A /40%
YES
Supplied as standard with the equipment.
Automatic
Automatic
Digital as standard.
YES
IP 23 S
35-50-70 mm2
H (180 ºC)
190 x 412 x 572 mm
23 Kg.
