5.2.3 Conversion from normal cutting to flush cutting
Note
The front section of the saw arm can be converted to allow flush cuts to be made (e.g. as close as
possible to edges and walls).
▶ If you wish to use the product in the flush cutting position, have the product converted by Hilti Service.
5.3 Locking rotary movement of the guide wheels
WARNING
Risk of injury. The saw could move inadvertently or fall down.
▶ When working on roofs, scaffolds and/or on slightly sloping ground or surfaces, always take steps
to prevent rotation of the guide wheels when the saw is not in use.
1. Release the guide wheel mounting screws and remove the guide wheels.
2. Reverse the guide wheels (turn through 180°) and refit the mounting screws.
◁ The integrated locking function is active.
3. Check that the guide wheels are securely fastened.
5.4 Mounting the gasoline-powered saw on the saw trolley (accessory)
1. Remove the water tank from the saw trolley.
2. Move the cutting depth adjustment lever into the upper position.
3. Open the hold-down device by releasing the screw knob.
4. Fit the saw into the forward mount with the wheels as shown and swing the grip of the saw under the
hold-down device.
5. Secure the saw by tightening the screw knob.
6. Fit the water tank after filling it.
7. Adjust the grip to a convenient working height.
8. Adjust the guard to the correct position. → page 31
Note
Especially when using the machine in this configuration for the first time, check to ensure that the
throttle cable is correctly adjusted. When the throttle trigger is pressed fully, the product must run
up to maximum speed. If this is not the case, the throttle cable can be readjusted by way of the
cable tensioner.
When the throttle is not actuated, the engine must be idling and the cutting disc must not rotate.
If this is not the case, switch off by pushing the start/stop switch to the "stop" position and then
adjust the throttle cable or have the idling speed adjusted by Hilti Service.
5.5 Fitting the water pump (accessory)
1. Release the three pump cover retaining screws, remove the parts and store the pump cover in a safe
place.
Note
The pump cover must be fitted if the product is used without the water pump.
2. Bring the water pump into place while rotating the cutting disc slightly until the toothing on the water
pump and inside the clutch housing match and the teeth mesh correctly.
◁ The position is keyed so it is not possible to position the pump incorrectly.
3. Fit the three retaining screws and tighten them securely (tightening torque: 4 Nm).
4. Connect the pump hose to the hose connector on the saw.
5. Connect the water pump to the water supply or hang the suction hose in a container filled with water.
Note
The maximum permitted water supply pressure is 6 bar.
