Display of the motor torque values during operation of the motorisation

During the opening and closing phases, four fi gures separated by a dot are displayed on the screen, for example 35.40. The
fi gures are updated whilst the gate is moving. They represent the actual torque used (35) and the torque set during the self-
learning procedure (40).
These values enable the torque entry to be corrected.
If the value of the actual torque used during movement of the gate more or less approaches the value of the programmed torque,
operating faults may occur in the future, due to wear or slight warping of the gate.
If the value of the actual torque used exceeds the value of the programmed torque, the gate will stop and reverse by several
centimetres.

TECHNICAL SPECIFICATIONS

Power supply
Motor power supply
Motor revolutions
Power consumption
Maximum consumed current
Reduction ratio
Revolutions at output
Pinion
Gate speed
Maximum weight of the gate
Maximum torque
Lubrication
Manual manoeuvres
Obstacle detection
Number of cycles/day
Control unit
Backup batteries (optional)
Operating temperature
Index protection rating
Weight
Dimensions
Accessories power supply
Automatic closure time
Operating time
Pedestrian opening time
Reversal pause
Integrated fl ashing amber light connection
Fuses
Built in radio receiver
Number of memorizable remote controls
RTS remote control frequency
Aerial resistance
Copyright © 2008 Somfy SAS. All rights reserved.
MOTOR
230 V 50/60 Hz
24 Vdc
3500 rpm
70 W
0.5 A (23 Vac) - 1 A (110 Vac)
1/44
79 rpm
4 mm module (14 teeth)
12 m/min
500 kg
20 Nm
Permanent grease
Mechanical release with handle
Electronic torque limiter
30
Built in with LCD display
Two 12 V 1.2 Ah batteries
-20 °C to +60 °C
IP24
7 kg (~ 70 N)
see "General motor size" pg.3
ELECTRONICS
24 Vac (180 mA)
between 3 and 120 seconds
120 s
7 seconds (fi xed)
1 second approximately
24 V maximum 25 W
250 V T 0.62 A and T 1 A
RTS
36
433.42 Mhz
50 Ohm (RG58)
Elixo 500 24 V
