Product description

2 Product description
Live view
1.0 Nm 1.0 Nm
50.0 % 50.0 %
1
2
70
The 3D L.A.S.A.R. Posture is a measuring device inten­
ded for verifying and optimising the static alignment of
prostheses and orthoses together with the patient.
The product's main components are a force measure­
ment plate in two sections, two camera stands with two
cameras each, a case, a mini-computer with power
supply, a tablet with inserted micro-SD memory card
and a battery charger with USB cable.
With the patient standing on the force measurement
plate, the vertical and horizontal ground reaction forces
as well as the torsion moments are measured. The mini-
computer sends the data from the cameras and the
force measurement plate to the tablet over the WiFi. On
the tablet, the data are graphically overlaid onto the live
camera shots in the form of load lines.
In 3D mode the blue and green load lines are based on
the vertical and horizontal ground reaction forces.
When 3D mode is deactivated, the load lines are red
and based only on the vertical ground reaction forces.
As with the 743L100=* L.A.S.A.R. Posture, they consti­
tute a vertical line above the resulting load transmission
point. This mode is compatible with the 743L100=*.
The static alignment of a prosthesis or orthosis can
Live view
therefore be verified according to the alignment recom­
mendations in the respective instructions for use.
The app includes a patient database and is able to out­
put patient data in the form of PDF files or in a special
format for the Ottobock Data Station.
1.0 Nm 1.0 Nm
50.0 % 50.0 %
1
2
743L500 3D L.A.S.A.R. Posture
