CYCLE PARAMETERS FOR PULSED MIG WELDING MODE IN CONTINUOUS CYCLE
Parameter
D Drop release force correction.
MOD Pulse mode (2T, 4T and 4T special)
TPR Gas pre-flow time.
IS Initial current (just in 4TS mode)
Current ramp-down time in arc-start and arc-end. (just in
DWS
4TS mode)
IE End crater current (just in 4TS mode)
TPS Gas post-flow time.
FDC Approach speed.
TBB After-burning time correction.
DIM Dimensional system (Ø/vh).
REF Cooling mode
tacer The time in approach process (Limited).
tci Time of interrupted cycle (Limited)
Troff2 Cooling disconnection time (AUT Mode)
4TS pulse mode signalling :
The "Special" 4TS mode will be indicated with the symbol ↑↓ situated further to the right, and which will be
flashing.
GALA INVERMIG SYNER 230 MP Bi-PULSE
PARAMETER DESCRIPTION
CONFIGURABLE
FACTORY VALUE
VALUE
-10 ÷ 10
(20 positions)
2T ; 4T ; 4TS
0÷3.0 sec.
50÷400% vh
0÷10.0 sec.
10÷200% vh
0.0÷5.0 sec.
10 ÷100% Vh
-20 ÷ 20 (ms)
MM ; IN
AUT/ON/OFF
Not adjustable
value
Not adjustable
value
Not adjustable
value
56
0
2T
0.3 (sec.)
200 % vh
0.6 (sec.)
50% vh
0.5 (sec.)
33 (% vh)
0.00
MM
---
5 s max.
4 s max.
120 sec.
